What is pLEV™
Designed by Australia’s leading air quality engineers, pLEV™ (portable Local Exhaust Ventilation) is an air-operated cleaning tool used for safe and effective cleaning of electrical cabinets. pLEV™ safely lifts and removes dust particles that fill electrical cabinets and components through the use of controlled forced air and extraction technology.
A dust control system that eliminates operator exposure risk
The pLEV™ system is the first portable cleaning technology on the market that is compliant with mine inspectorate occupational exposure limits for respirable dust.
Enquire nowProtect your staff from respirable silica exposure
Compare pLEV™ technology to existing dust cleaning controls
Protect your staff from respirable silica exposure
Compare pLEV™ technology to existing dust cleaning controls
Without pLEV™
With pLEV™
Products
Our technology is Australian invented, developed, designed and manufactured
Download product guide
pLEV™ Extractor
Extracts and filters dust
pLEV™ SmartLance HP
Compressed air supply tool
pLEV™ SmartLance EX
Portable air supply tool
pLEV™ Covers
Seals the cleaning zone
pLEV™ Workshop Trolley
Secure storage
Compressed Air Filtration
Clean compressed air
pLEV™ HiFlow Extractor
Greater capacity and flow rate
Save your company time and money by increasing productivity
- pLEV™ prevents unsafe airborne dust exposure
- pLEV™ enables the cleaning of dust-ridden electrical cabinets while avoiding exposure risk to the operator
- pLEV™ system monitors compressed air supply pressure
- pLEV™ compressed air control maintains OEM recommended air pressure standards
- pLEV™ technology immediately alerts the operator of any unsafe exposure or equipment risk
- Failsafe technology ensures pLEV™ shuts off air supply when operated outside safe parameters
- Harmful dust particles are safely extracted through a multi-stage filtration system while pLEV™ releases clean air
- Requires no additional PPE
The heart of the pLEV™ system! The pLEV™ Extractor is the component that safely extracts airborne dust created through the electrical cabinet cleaning process.
The dust is extracted using a 2 kW, multi-stage extraction fan. The air is filtered three times, first through a cyclone system, then through a secondary cartridge filter, and finally through a HEPA filter. The air out of the pLEV™ Extractor exhaust is clean.
Negative pressure and vacuum is a constant while the pLEV™ Extractor is operational, ensuring dust is contained at all times.
- Coarse and (HEPA-rated) fine dust filtration
- Differential pressure sensors for max flow rate assurance & blinded filter detection
- 2 kW, two-stage fan with motor temperature monitoring
- Warning LED array for system fault detection
- Ergonomic harness for portability
- Fail-safe system shuts down fan in the case of threshold exceedances
- Minimises both primary and secondary dust exposures
The pLEV™ SmartLance HP (High Pressure) enables the use of compressed air in the extraction environment. It features illumination, exposure monitoring, compressed air pressure control and cloud-based reporting.
The lance monitors exposure through air quality sensors with shutdown technology at the ready if an exposure event occurs. The lance is also fitted with negative pressure sensors which prevent lance use outside the intended purpose and parameters.
- Compressed air control
- Cuts off compressed air supply according to OEM limits
- Only permits compressed air use when cabinet is sealed and pLEV™ Extractor is functional
- LCD for displaying system status, warnings & errors
- LED array for higher visibility in cleaning area
- Self-verifying particulate sensor array in operator's breathing zone
- System warning/shutdown in the event of an exposure exceedance
- Optional cloud-based reporting
The pLEV™ SmartLance EX (Exhaust) is an alternative to traditional compressed air cleaning of electronics. Instead of using compressed air to dislodge dust in the cabinet (like the pLEV™ SmartLance HP), the pLEV™ SmartLance EX uses the exhaust air of the pLEV™ Extractor.
The lance monitors exposure through air quality sensors with shutdown technology at the ready if an exposure event occurs. The lance is also fitted with negative pressure sensors which prevent lance use outside the intended purpose and parameters.
- Dislodges dust without the use of compressed air
- Wireless communication between pLEV™ SmartLance EX and pLEV™ Extractor to control cleaning flow rate
- Only permits cleaning air use when cabinet is sealed and pLEV™ Extractor is functional
- LCD for displaying system status, warnings & errors
- LED array for higher visibility in cleaning area
- Self-verifying particulate sensor array in operator's breathing zone
- System warning/shutdown in the event of an exposure exceedance
- Optional cloud-based reporting
pLEV™ Covers are completely transparent, lightweight, durable and tailored to most common electrical cabinets and components. The covers are used to seal the cabinet - minimising the risk of potential dust exposure. The correct fit of cover to cabinet is essential.
Current designs are suitable for Komatsu, Liebherr, Caterpillar truck components and equipment. pLEV™ also supports the effective and safe cleaning of MG set and electric motors.
- Fit for purpose and application
- Cabinet covers have been designed and manufactured for:
- Dragline generators
- Horizontal/vertical axis dragline motors
- MG sets
- Diesel electric truck alternators
- Diesel electric truck cabinets of various dimensions
- Contact pLEV™ RND for custom applications
The pLEV™ Workshop Trolley is the best option for safe and secure storage and protection of pLEV™ equipment. It offers storage for all pieces of equipmentincluding: pLEV™ Extractor, SmartLances, covers, hoses, cables, fittings, filters, catch cans, consumables and more. With all the equipment in one location, you will save time and money on your service schedule.
Additionally, the pLEV™ Workshop Trolley is fitted with a compressed air/filtration system to ensure only clean air is ever used around your electrical equipment.
- Safe, protected storage for all pLEV™ equipment
- Compressed air filtration system
The pLEV™ Compressed Air Filtration System is the best option for safe and clean compressed air. The filtration system removes particulate, oils, and moisture from the supply, ensuring only clean compressed air is used around electrical equipment. The regulator allows the operator to reduce the pressure supplied by the system to ensure OEM specifications are met.
- Mist and micro mist seperator's remove 99.9% of particles >0.3um.
- Membrane dryer reduces moisture in supplied air
With 3x the filter surface area and 75% more flow rate than the pLEV™ Extractor, the HiFlow Extractor is designed for applications that require greater extraction. The pLEV™ HiFlow Extractor safely removes and collects airborne dust from enclosed environments.
The dust is extracted using a 2 kW, single-stage fan. The air first travels through a cyclone filter, which separates the heavier particles. The finer particles are then captured in a large capacity HEPA rated cartridge filter. The air exhausted from of the pLEV™ Extractor is clean.
An array of sensors detect the status of the cyclone container and cartridge filter to ensure the device is operating safely.
When used in conjunction with pLEV™ Covers, the Extractor ensures dust is contained at all times.- Coarse and (HEPA-rated) fine dust filtration
- Differential pressure sensors for max flow rate assurance & blinded filter detection
- Five times larger volume cyclone filter container over the standard pLEV™ Extractor
- 2 kW, single-stage fan for greater extraction flow rate
- Warning LED array for system fault detection
- Ergonomic harness for portability
- Fail-safe system shuts down fan in the case of threshold exceedances
- Minimises both primary and secondary dust exposures
